Deck Equipment :
| » |
Custom Stainless Steel stemhead with double bow roller, one fitted with a 27.5kg plough anchor and 50 metres of 10mm chain. |
| » |
Anchor dam |
| » |
Chain deflector |
| » |
Heavy duty 1200W electric anchor winch |
| » |
Large self draining anchor locker divided into two compartments |
| » |
Stainless steel bow pulpit with teak seat. |
| » |
Stainless steel stern pushpit with seat frames, teak seats and teak back rest. |
| » |
Stainless steel helms seat with teak seat and backrest, hinged off pushpit for access to transom. |
| » |
Stainless steel handrails between pushpit and S/S "A" frame side gates with boarding steps and teak cover to steps. |
| » |
Stainless Steel stanchions with double life lines. |
| » |
2 Fwd and 2 aft fairleads and mooring cleats |
| » |
2 Midship cleats |
| » |
7 Alloy deck hatches |
| » |
9 Opening portholes |
| » |
6 Fixed portholes |
| » |
4 Large deck drains |
| » |
1 Saltwater deck wash (accessed from anchor locker) |
| » |
Genoa main track to side decks and inner foresail tracks to foredeck |
| » |
2 @ Fuel filler (one each side) |
| » |
2 @ Water filler (one each side) |
| » |
1 @ Blackwater deck pump out. |
Transom:
| » |
Platform moulded in transom |
| » |
Non skid fiberglass to standing areas |
| » |
Built in fiberglass steps to cockpit |
| » |
Stainless steel swim ladder with teak treads |
| » |
Freshwater transom shower |
| » |
Transom light |
| » |
Stainless steel bumprail |
| » |
Gas bottle locker with 2 bottles |
Generator :
| » |
7kw Onan generator |
| » |
Racor fuel filter |
Bow Thruster : Mast & Rigging :
| » |
Keel stepped alloy mast |
| » |
Double spreader rig |
| » |
Two deck lights to u/s of lower spreader |
| » |
Intermediate, lower and deck shrouds |
| » |
Dyform type stainless steel standing rigging with swaged terminals |
| » |
2 @ Backstays |
| » |
1 @ Forestay |
| » |
1 @ Inner forestay (removable with stainless steel ratchet tension adjuster) |
| » |
Leisure Furl alloy boom with hydraulic furling system (incorporating halogen light to u/s) |
| » |
Stainless steel Shroud Rollers |
| » |
Stainless steel boom brake |
| » |
Stainless steel fixed boom vang |
| » |
Roller headsail furling system |
| » |
Two running backstays |
| » |
Additional halyards for spinnaker, staysail etc |
| » |
Spinnaker pole and track to mast |
| » |
2 x manual winches to mast |
| » |
Genoa and staysail tracks |
| » |
Traveler track to cabin top |
| » |
All sheets, halyards, deck blocks, stand up blocks, cars and brakes for all sheets |
| » |
Flag halyards |
| » |
Windex |
| » |
Mainsail (48 sqm) and Genoa 130% (59 sqm) |
Head & Ensuite:
| » |
Shower, toilet and vanity unit |
| » |
One piece fiberglass moulding |
| » |
Caroma Cube china basin semi recessed into corian top |
| » |
Broadware Tapsets stainless steel |
| » |
Electric Toilets are fresh water flush |
| » |
Hot and cold pressurised water |
| » |
Corian bench tops with corian fiddles |
| » |
2 x overhead lights (halogen) |
| » |
1 x 240 volt outlet |
| » |
Automatic discharging shower sump |
| » |
Hand held shower |
| » |
Vanity Mirror |
| » |
Teak/Cherry towel rail |
| » |
1 x overhead stainless steel towel rail to shower cubicle |
| » |
1 x deck hatch |
| » |
1 x Opening port hole |
| » |
Overhead teak/cherry locker |
| » |
Teak shower grates |
| » |
Teak laid floor |
| » |
Teak laid shower seat |
| » |
Soap dispenser and toothbrush holders |
Port Aft Cabin & Starboard Aft Cabin:
| » |
Soft leatherette headliner |
| » |
Teak/Cherry faced bulkheads and Teak/Cherry paneled bunk sides |
| » |
Teak/Cherry full length shelf and fiddle |
| » |
Double bunk berth. |
| » |
125mm Mattress |
| » |
Teak/Cherry hanging locker |
| » |
Teak/Cherry dresser with cupboard and drawers |
| » |
Storage under bunk |
| » |
1 x Overhead light (Halogen) |
| » |
1 x Reading light (Halogen) |
| » |
Opening portholes |
| » |
Solid teak & ash laid floor |
| » |
Teak cabin door |
| » |
Teak/Cherry access door to lazarette |
Guest Cabin (Family layout only):
| » |
Soft fabric or Leatherette headliner |
| » |
Teak/Cherry faced bulkheads |
| » |
Upper and lower single bunks |
| » |
125mm Mattresses |
| » |
Teak/Cherry hanging locker |
| » |
Teak/Cherry storage locker/Cupboards |
| » |
Overhead cupboard |
| » |
Storage under bunk |
| » |
2 x reading lights (Halogen) |
| » |
1 x underdeck light |
| » |
Solid teak & ash floor |
| » |
Deck hatch |
| » |
Opening porthole |
| » |
Fixed porthole |
| » |
Teak cabin door |
Inside Helm Station :
| » |
Teak/Cherry console and dashboard. Electrical cabinet and switchboard panel and breakers. |
| » |
Engine controls, warning lights, audible alarm, oil pressure, water temperature gauge, tachometer, voltmeters etc. |
| » |
Stainless steel engine throttle control with Cockpit/Inside Helm selector. |
| » |
AC and DC monitoring with Invertor controls |
| » |
240 volt, 24 volt and 12 volt instrumentation board. |
| » |
Auto pilot Raymarine ST 8002. |
| » |
Wind instrument direction and speed. |
| » |
Tridata instrumentation, speed, depth and log. |
| » |
VHF radio |
|
Cockpit :
| » |
Moulded fibreglass self draining deck. |
| » |
3 Storage lockers |
| » |
2 Pushpit teak bench seats |
| » |
Stainless steel and teak helmsman seat |
| » |
Teal laid cockpit floor and teak laid seats to locker tops |
| » |
Teak standing platform across helm |
| » |
New design Steering Pedestal with Head and Command Console |
| » |
Stainless steel Helm wheel, compass and hydraulic steering to pedestal head |
| » |
Auto Pilot |
| » |
Combination wind speed and direction instrumentation. |
| » |
Tridata instrumentation, depth, speed, log |
| » |
Stainless steel engine throttle control |
| » |
Bow Thruster control |
| » |
Electric/hydraulic main sail furling controls |
| » |
Main and secondary winch hydraulic controls (2 speed) |
| » |
Anchor control |
| » |
Engine Start Stop control |
| » |
2 Electric/hydraulic genoa winches (2 gears) |
| » |
2 Electric/hydraulic secondary winches (2 gears) |
| » |
Fold down stable door to saloon |
| » |
Cockpit table with ice box stowage |
Electrical:
| » |
One 12 volt battery for engine/generator start |
| » |
One 12 volt battery for 12 volt auxillary |
| » |
Six @ 6 volt house service batteries 400 amp @ 24 volt |
| » |
One 24 volt 140 amp engine driven alternator |
| » |
One 12 volt 80 amp engine driven alternator |
| » |
One 12 volt 20 amp generator driven alternator |
| » |
One 24 to 12 volt dc to dc convertor |
| » |
240 volt stainless steel shore power inlet |
| » |
4 x 240 volt outlets |
| » |
1 x 12 volt outlet |
| » |
16 x 24 volt halogen lights (interior) |
| » |
8 x 24 volt halogen reading lights |
| » |
Navigation lights |
| » |
Anchor light |
| » |
Combination steaming/deck light |
| » |
Cockpit light |
| » |
Light to underside of boom to cockpit |
| » |
12 volt panel with breakers |
| » |
240 volt panel with breakers |
| » |
Battery isolation switches |
| » |
2 x Bilge pumps |
| » |
1 x Deck wash pump (salt) |
| » |
1 x Hydraulic pump |
| » |
5 x Engine room lights |
| » |
1 x Shower/bathroom/galley sump pump |
| » |
1 x Fresh water pump |
| » |
1 x 2000w Inverter/battery charger |
Engine Room :
| » |
Foam metal lined soundproofing |
| » |
110hp Yanmar turbo diesel |
| » |
7 kw Onan Generator |
| » |
Racor glass bowl fuel filters |
| » |
Stainless steel fuel lines |
| » |
3 x Engine room lights |
| » |
1180 litre dual fuel tanks |
| » |
644 litre dual water tanks |
| » |
Fuel and water balancing, drain and feed lines |
| » |
40 litre hot water unit |
| » |
Freshwater pressure pump |
| » |
Saltwater deck wash pump |
| » |
Ball valves on all skin fittings |
| » |
38mm stainless steel propeller shaft |
| » |
Tri stream stainless steel folded 4-bladed propeller |
| » |
2 x Electric bilge pump (fwd & engine compartments) |
| » |
1 x Manual bilge pump |
| » |
240 volt and 24 volt Refrigeration compressor |
| » |
2 x Refrigeration pumps and header tanks |
| » |
Holding tank (black water) with macerator pump |
| » |
Hydraulic power pack, pump, valve banks. |
Main Engine:
| » |
110hp Yanmar turbo diesel with marine gears |
| » |
Freshwater cooling |
| » |
Alternator 140 amp 24 volt and 80 amp 12 volt |
| » |
Racor Fuel filter |
Galley :
| » |
Corian galley top with corian fiddle |
| » |
Teak/Cherry cupboards |
| » |
Teak/Cherry pantry cupboards and drawers |
| » |
Solid teak and ash laid floor |
| » |
Teak/Cherry faced bulkheads |
| » |
Teak/Cherry "v" jointed boarded headliner |
| » |
Teak/Cherry Galley floor hatch in two sections for under floor storage |
| » |
Gimbaled gas stove and oven |
| » |
Microwave |
| » |
Dual bowl Stainless steel sink |
| » |
Broadware Tapsets |
| » |
Hot and cold pressurised water |
| » |
240 volt and 24 volt driven eutectic refrigerator |
| » |
240 volt and 24 volt driven eutectic freezer |
| » |
3 x under bench lights (Halogen) |
| » |
3 x Overhead lights (Halogen) |
| » |
1 x 240 volt double outlet |
| » |
1 x Large deck hatch |
| » |
1 x opening deck port hole |
Forward Stateroom :
| » |
Soft leatherette headliner |
| » |
Teak "v" jointed boarding to cabin sides |
| » |
Teak/Cherry faced bulkheads |
| » |
Double/Queen berth with Teak/Cherry fiddle |
| » |
150mm Mattress |
| » |
Four seater leather lounge with storage under (Island Bed layout only) |
| » |
Teak/Cherry overhead cupboards and shelves |
| » |
Teak/Cherry hanging lockers and shelf arrangements |
| » |
Teak/Cherry storage lockers |
| » |
Storage under bunk |
| » |
2 x large deck hatch |
| » |
3 x overhead lights (Halogen) |
| » |
2 x reading lights (Halogen) |
| » |
2 x fixed portholes |
| » |
Solid teak & ash laid floor |
| » |
Teak cabin door |
| » |
24 volt power outlet |
Saloon:
| » |
Laminated 13mm tinted safety glass windows |
| » |
Soft leatherette headliner panels with dual Teak/Cherry grab rails to ceiling |
| » |
"L" shape main lounge settee leather upholstered. |
| » |
Leather upholstered Helm seat on Stainless pedestal. |
| » |
Teak/Cherry dinette table (extendable) |
| » |
Teak/Cherry cocktail cabinet on starboard side |
| » |
Teak/Cherry handrails to galley |
| » |
Teak steps down to galley |
| » |
Solid teak & ash laid floor |
| » |
Engine access hatches with in lay "B" logo |
| » |
2 x overhead deck hatches |
| » |
6 x overhead lights (halogen) |
| » |
1 x 12 volt power outlet |
| » |
1 x 240 volt power outlet |
| » |
1 x "Dago" double arm window wiper |
| » |
10 x verosol blinds |
| » |
CD, Audio Entertainment |
|
